Rock Pagoda Nozzle
Made of wear-resistant steel and diamond composite, it sprays high-pressure water to clear pipeline dirt. Replaceable ceramic parts prolong service life for drain pipe blockage removal.
Product Variants & Specifications
Choose a variant to view detailed specifications
| Model | Hose Connection | Flow (LPM) | Pressure (Bar) | Rear Jets | Dimensions (mm) Φ x L | Working DN (mm) | Weight (Kg) | Rotating Jets |
|---|---|---|---|---|---|---|---|---|
 BT0.5 | 3/8" F | 60 | 137 | 6 x M6 | 36 x 107 | 60-150 | 0.5 | 4 x M6 |
 BT1.2 | 3/4" F | 170 | 137 | 6 x M6 | 50 x 136 | 80-200 | 1.2 | 4 x M6 |
 BT3.3 | 1" F | 215 | 172 | 6 x M10x1 | 75 x 159 | 100-300 | 3.3 | 4 x M10x1 |
 BT5 | 1" F | 215 | 172 | 6 x M10x1 | 75 x 207 | 100-300 | 5 | 4 x M10x1 |
About This Product
The nozzle is made of wear-resistant hardened stainless steel and diamond composite. High-pressure rotating water jets from the pump impacts the dirt and deposits from pipelines by its strong kinetic energy, so as to achieve the purpose of cleaning & penetrating. All ceramic inserts are replaceable, which extend the service life several times than drilled nozzles. Application: Removing blockage such as blocks, lime, grease, sediment, roots, etc. from various types of pipelines, e.g. rainwater pipes, sewage pipes. Interface Thread: NPT or BSPP Max Pressure: 172Bar. Different flows and pressures are available on request.
